SOLIDWORKS Macro to Delete All Configurations Except the Active One

Description

• Deletes every configuration except the active one from the active part or assembly.
• Asks for confirmation first and reports how many configurations were removed.
• Optionally renames the remaining configuration to “Default”.

System Requirements

• SOLIDWORKS Version: SOLIDWORKS 2014 or newer
• Operating System: Windows 10 or later

Pre-Requisites

• The active document must be a part or an assembly with more than one configuration.
• Activate the configuration you want to keep before running the macro.

Results

• Only the active configuration remains.
• Set RENAME_TO_DEFAULT to True at the top of the code to rename it to “Default”.

Steps to Set Up the Macro

1. Open SOLIDWORKS and the document described in the pre-requisites.

2. Create the macro

• Go to Tools > Macro > New, give the .swp file a name and save it. The VBA editor opens.
• Replace everything in the module with the code below.

3. Run the macro

• Press F5 in the VBA editor, or use Tools > Macro > Run.
• For daily use, assign it to a toolbar button or keyboard shortcut via Tools > Customize.

VBA Macro Code

' Disclaimer:
' The code provided should be used at your own risk.
' Blue Byte Systems Inc. assumes no responsibility for any issues or damages that may arise from using or modifying this code.
' For more information, visit https://bluebyte.biz
' Reviewed and updated by Blue Byte Systems Inc.

Option Explicit

' Deletes every configuration except the active one from the active part or assembly.
' Set RENAME_TO_DEFAULT to True to rename the remaining configuration to "Default".

Const RENAME_TO_DEFAULT As Boolean = False

Sub main()
    Dim swApp As SldWorks.SldWorks
    Dim swModel As SldWorks.ModelDoc2
    Dim swConfig As SldWorks.Configuration
    Dim vNames As Variant
    Dim activeName As String
    Dim i As Long
    Dim deleted As Long

    Set swApp = Application.SldWorks
    Set swModel = swApp.ActiveDoc

    If swModel Is Nothing Then
        MsgBox "Open a part or assembly before running this macro.", vbExclamation
        Exit Sub
    End If
    If swModel.GetType <> swDocPART And swModel.GetType <> swDocASSEMBLY Then
        MsgBox "The active document must be a part or an assembly.", vbExclamation
        Exit Sub
    End If
    If swModel.GetConfigurationCount < 2 Then
        MsgBox "Only one configuration exists in this model.", vbInformation
        Exit Sub
    End If

    Set swConfig = swModel.ConfigurationManager.ActiveConfiguration
    activeName = swConfig.Name

    If MsgBox("Delete " & (swModel.GetConfigurationCount - 1) & " configuration(s) and keep '" & _
              activeName & "'?" & vbCrLf & "This cannot be undone.", vbYesNo + vbQuestion) <> vbYes Then Exit Sub

    vNames = swModel.GetConfigurationNames
    For i = 0 To UBound(vNames)
        If vNames(i) <> activeName Then
            If swModel.DeleteConfiguration2(vNames(i)) Then deleted = deleted + 1
        End If
    Next

    If RENAME_TO_DEFAULT Then
        swConfig.Name = "Default"
        swConfig.UseAlternateNameInBOM = False
    End If

    swModel.ForceRebuild3 False
    MsgBox deleted & " configuration(s) deleted.", vbInformation
End Sub

Code Review Notes

We reviewed this macro before publishing it here. Changes from the original version:

• The original needed a separate UserForm that was not published with the code. It now runs from a single module with a confirmation prompt.
• Fixed an undefined variable that stopped the macro from compiling.
