How to Export Flat Patterns with PDMPublisher
With PDMPublisher, exporting flat patterns from a top-level SOLIDWORKS assembly is completely automated and requires no manual steps.If you have ever wondered how to export flat patterns with PDMPublisher in a reliable, hands-off way, this workflow makes the entire process effortless. Step 1: Set the Export Location In this example, the export location is defined as the DXF subfolder inside the C:\Export directory. By enabling “Export file references individually,” both the main assembly and its referenced parts will be processed automatically. Step 2: Enable Flat Pattern Export Next, check the option “Export sheet metal part to 1:1 flat pattern DXF.”This ensures that only sheet metal components are exported as clean, accurate flat patterns that are ideal for manufacturing. Step 3: Define the Naming Convention File names are automatically built using the part number (or item name) followed by the revision.This keeps every exported file organized and traceable within your vault or output folder. Step 4: Apply Filters (Optional) To avoid processing every component, you can apply filename filters.In this case, the export was limited to parts named base_shape and control_panel, allowing targeted processing for selected models. Step 5: Publish Finally, click Publish.PDM Publisher will begin processing the top-level assembly and its references, loading them into memory, extracting each flat pattern, and saving them to the target folder automatically. Step 6: Review the Results Once complete, your DXF flat pattern files are ready for fabrication, organized, clean, and consistent.
