This macro allows you to export the active document as a STEP file to the same directory as the original file. It will automatically name the STEP file the same as the active document, but with the .step extension. This macro is an easy way to export parts and assemblies to STEP files.

You can download an icon for the macro at this link to use when you add it as a button on a toolbar.

System Requirements

●   SolidWorks Version: SolidWorks 2014 or later

●   Operating System: Windows 7 or later

Pre-Conditions

●   The active document must be a part or assembly.

●   This macro does not work on drawing files.

●   Ensure that the document is saved before running the macro, as it will export the file in the same directory.

Results

●   The macro will save the active document as a .step file in the active document’s directory.

●   A message box will show you where the file was saved.

VBA Macro Code

' Disclaimer:
' The code provided should be used at your own risk.
' Blue Byte Systems Inc. assumes no responsibility for any issues or damages that may arise from using or modifying this code.
' For more information, visit [Blue Byte Systems Inc.](https://bluebyte.biz).

Dim swApp As SldWorks.SldWorks
Dim Part As ModelDoc2
Dim boolstatus As Boolean
Dim longstatus As Long, longwarnings As Long

Sub main()

    ' Initialize SolidWorks application and active document
    Set swApp = Application.SldWorks
    Set Part = swApp.ActiveDoc

    ' Exit if no document is active
    If Part Is Nothing Then Exit Sub

    ' Get the path of the active document
    Dim Path As String
    Path = Part.GetPathName

    ' Exit if the active document is a drawing (since STEP export is not supported for drawings)
    If Part.GetType = swDocDRAWING Then
        Exit Sub
    End If

    ' Prepare the path for the STEP file by replacing the extension
    Dim Extension As String
    Extension = Mid(Path, InStrRev(Path, "."))
    Path = Replace(Path, Extension, ".step")
    Extension = ".step"

    ' Export the file as STEP
    longstatus = Part.SaveAs3(Path, 0, 0)

    ' Notify the user about the saved file location
    MsgBox "Saved " & Path, vbInformation
End Sub

You can download the macro from here.
