AUTOMATING DRAWING DOCUMENT RELEASE PROCESS: INCREASE EFFICIENCY WTH PDMPUBLISHER

INTRODUCTION

BLUE BYTE SYSTEMS INC. specializes in SOLIDWORKS PDM automation, streamlining engineering and manufacturing workflows.

Our flagship tool, PDMPublisher, automates PDF, DXF, STEP files generation, merging, and adding custom notes, eliminating manual steps for efficient, error-free, and cost-effective document management.

CHALLENGE

A Pacific North West Manufacturing faced time-consuming PDF printing, merging, and quantity management.

Their manual workflow involved:

  • Printing documents individually.
  • Adding production quantities to the printed documents using Adobe Acrobat.
  • Merging printed documents into manufacturing packages.

Between 2023-2024, they processed tens of thousands of PDFs and merged several thousands packages.

SOLUTION

To address these challenges, Pacific North West Manufacturing Company implemented PDMPublisher, enabling:

  • Automated PDF generation from one single click from the top-level assembly.
  • Smart document selection via conditions.
  • Automated PDF merging.
  • Placement of custom notes in all documents such as Bill Of Materials quantities.

RESULTS

By leveraging PDMPublisher, Pacific North West Manufacturing company achieved.

Manual Process

Finding Drawings

Filtering Documents

Print & Merging PDFs

Adding Bill Of Materials Quantities

Total Time Per Package

Total Annual Time

Annual Cost

1-5 min

5-10 min

10-15 min

3-5 min

19-35 min

+1000 hours

+$50,000

With PDM Publisher

How Much Can You Save?











CONCLUSION

The Return On Investment with PDMPublisher

By automating the document selection, merging, and manufacturing quantity addition process, PDMPublisher has transformed the company’s workflow. The solution has saved hundreds of hours per year, reduced operational costs, and improved accuracy.

For manufacturing companies managing high volumes of engineering documents, PDMPublisher provides a scalable, error-free, and cost-effective automation tool, allowing teams to focus on higher-value engineering and production tasks rather than repetitive administrative work.
